- Lettering placement is strategically located to avoid top of shackle bow to prevent fraying of synthetic slings. 1 per EA
- Included angle between markings provides a quick visual guide for checking the load angle for double and single leg hitches.
- Markings of shackle include Date Code. WLL and Size on one side and Campbell. USA and CE on the other.
- Drop forged for superior strength and performance.
- 5:1 design factor.
- Bail Size=1/2 in.
- Color=Orange.
- Finish=Galvanized.
- Inner Length [Nom]=1 15/16 in.
- Inner Width [Nom]=1 1/4 in.
- Locking Type=Bolt.
- Material=Forged Alloy Steel.
- Opening Size [Nom]=13/16 in.
- Pin Size [Nom]=5/8 in.
- Type=Bolt Shackle.
- Working Load Limit=3 1/3 t.
- Wt.=0.88 lb.
- Lettering placement is strategically located to avoid top of shackle bow to prevent fraying of synthetic slings.
- Included angle between markings provides a quick visual guide for checking the load angle for double and single leg hitches.
- Markings of shackle include Date Code. WLL and Size on one side and Campbell. USA and CE on the other.
- Drop forged for superior strength and performance.
- 5:1 design factor.
